Leeson, .50 Hp General Purpose Motor, 3 Phase, 1800 Rpm, 208-230/460 V, 56c Frame, Tefc, (102860.00)
Model(s): 102860.00
Availability: Available
Factory direct order.
Ships within 5-7 days.
Mfr. Part Number:
102860
Alt. Part Number:
2525151
Alt. Reference:
691720326404
Lead Time:
See details above
Optimize your woodworking machinery with this high-quality Leeson 102860.00 0.50 Hp General Purpose Motor, 3 Phase, 1800 Rpm, 208-230/460 V, 56c Frame, Tefc. This replacement part (102860.00) is engineered for precise fitment and professional-grade reliability.
102860.00
UPC: 691720326404 | UNSPSC: 26101100 | GTIN:
LEESON® AC Motor, Type TF Continuous Duty, Compressor Motors, Fan & Blower Motors Application, 4-Pole, B NEMA Design Special Features, 1/2 hp, 208 to 230/460 VAC, 2.1 to 2.2/1.1 A, 60 Hz Frequency, 1725 rpm Speed, 1 Speed, Totally Enclosed Fan Cooled (TEFC) Enclosure, 48 Frame, 5/8 in Dia Shaft, Reversible Rotation, 1.149 Service Factor, Ball Bearing, Round Mounting, 40 deg C, Insulation Class: Class B, Rolled Steel, 10.19 in L x 7.41 in W x 5.62 in H Dimensions
Features:
- Standard, EPACT and premium efficiency motor
- Shielded ball bearings for direct coupled applications
- Dynamically balanced rotors torques exceed NEMA performance standards
Specs:
- Type: Type TF Continuous Duty
- Material: Rolled Steel
- Dimensions: 10.19 in L x 7.41 in W x 5.62 in H
- Voltage Rating: 208 to 230/460 VAC
- Amperage Rating: 2.1 to 2.2/1.1 A
- Mounting Type: Round
- Frequency Rating: 60 Hz
- Speed: 1725 rpm
- Enclosure Type: Totally Enclosed Fan Cooled (TEFC)
- Temperature Rating: 40 deg C
- Bearing Type: Ball
- Frame: 48
- Rotation: Reversible
- Number of Speeds: 1
- Horsepower: 1/2 hp
- Shaft Size: 5/8 in Dia
- Insulation Class: Class B
- Application Type: Compressor Motors, Fan & Blower Motors
- Special Features: 4-Pole, B NEMA Design
- Service Factor: 1.149
Packaging:
- Weight: 18.0 lb
Certifications/Standards:
CSA Certified | UL Listed
