Leeson, 1 Hp General Purpose Motor, 1 Phase, 1800 Rpm, 115/208-230 V, 56c Frame, Tefc, (110058.00)
Model(s): 110058.00
Availability: Available
Factory direct order.
Ships within 5-7 days.
Mfr. Part Number:
110058
Alt. Part Number:
2525417
Alt. Reference:
691720007723
Lead Time:
See details above
Optimize your woodworking machinery with this high-quality Leeson 110058.00 1 Hp General Purpose Motor, 1 Phase, 1800 Rpm, 115/208-230 V, 56c Frame, Tefc. This replacement part (110058.00) is engineered for precise fitment and professional-grade reliability.
110058.00
UPC: 691720007723 | UNSPSC: 26101100 | GTIN: LEESON® AC Motor, Type CF Continuous Duty, Compressor Motors, Fan & Blower Motors Application, 4-Pole, N NEMA Design Special Features, 1 hp, 115/208 to 230 VAC, 13.6/6.8 A, 60 Hz Frequency, 1725 rpm Speed, 1 Speed, Totally Enclosed Fan Cooled (TEFC) Enclosure, 56 Frame, 5/8 in Dia Shaft, Selective CCW Rotation, 1.149 Service Factor, Ball Bearing, Round Mounting, 40 deg C, Insulation Class: Class B, Rolled Steel, 11.81 in L x 8.65 in W x 8.6 in H Dimensions
Features:
- Durable rolled steel construction
- Meets or exceeds NEMA service factors
- Double shielded ball bearings
- Thermally protected ratings
Specs:
- Type: Type CF Continuous Duty
- Material: Rolled Steel
- Dimensions: 11.81 in L x 8.65 in W x 8.6 in H
- Voltage Rating: 115/208 to 230 VAC
- Amperage Rating: 13.6/6.8 A
- Mounting Type: Round
- Frequency Rating: 60 Hz
- Speed: 1725 rpm
- Enclosure Type: Totally Enclosed Fan Cooled (TEFC)
- Temperature Rating: 40 deg C
- Bearing Type: Ball
- Frame: 56
- Rotation: Selective CCW
- Number of Speeds: 1
- Horsepower: 1 hp
- Shaft Size: 5/8 in Dia
- Insulation Class: Class B
- Application Type: Compressor Motors, Fan & Blower Motors
- Special Features: 4-Pole, N NEMA Design
- Service Factor: 1.149
Packaging:
- Weight: 36.0 lb
Certifications/Standards:
CSA Certified | UL Listed
