    Leeson, 3Hp Definite Purpose Ac Motor, 1 Phase, 3600 Rpm, 230 V, 145y Frame, Tefc, (120728.00)

    https://www.woodmachineryparts.com/web/image/product.template/2149/image_1920?unique=43f0124

    Model(s): 120728.00


    Availability: Available

    Factory direct order.


      Ships within 5-7 days.


    1,538.91 1538.91 USD 1,538.91

    1,538.91

    0.0% Off

      This combination does not exist.




      Sku​:
      MP-19-40
      Brand:  Leeson

      Have questions about this product?


      Mfr. Part Number: 120728
      Alt. Part Number: 2526178
      Alt. Reference: 691720015889
      Lead Time: See details above

      Optimize your woodworking machinery with this high-quality Leeson 120728.00 3 Hp Definite Purpose Ac Motor, 1 Phase, 3600 Rpm, 230 V, 145y Frame, Tefc. This replacement part (120728.00) is engineered for precise fitment and professional-grade reliability.

      120728.00

      UPC: 691720015889 | UNSPSC: 26101602 | GTIN:

      LEESON® AC Motor, 2-Pole Continuous Duty, Application Type: Saw Arbor Motors, Special Features: Capacitor Start Motors, 3 hp, 230 VAC, 13 A, 60 Hz, 1 ph, 3450 rpm, 1 Speed, Totally Enclosed Fan Cooled (TEFC), 145Y Frame, 3/4 in Dia x 1-3/4 in L Shaft, Fixed CCW, Service Factor: 1, Ball Bearing, 4.5 ft-lb, Round/C-Face Footless Mount, 40 deg C, Insulation Class: Class F, Rolled Steel, 10:1 Variable Torque Speed, 12.86 in L

      Features:

      • Motor pivots on rod for belt tensioning
      • Extra high breakdown torques for maximum cutting power
      • 3/4 in Dia x 1-3/4 in L with keyway

      Specs:

      • Type: 2-Pole Continuous Duty
      • Material: Rolled Steel
      • Dimensions: 12.86 in L
      • Voltage Rating: 230 VAC
      • Amperage Rating: 13 A
      • Mounting Type: Round/C-Face Footless
      • Frequency Rating: 60 Hz
      • Speed: 3450 rpm
      • Enclosure Type: Totally Enclosed Fan Cooled (TEFC)
      • Temperature Rating: 40 deg C
      • Bearing Type: Ball
      • Frame: 145Y
      • Rotation: Fixed CCW
      • Number of Speeds: 1
      • Horsepower: 3 hp
      • Phase: 1 ph
      • Torque Rating: 4.5 ft-lb
      • Shaft Size: 3/4 in Dia x 1-3/4 in L
      • Insulation Class: Class F
      • Application Type: Saw Arbor Motors
      • Special Features: Capacitor Start Motors
      • Service Factor: 1
      • Variable Torque Speed Range: 10:1

      Certifications/Standards:

      CSA Certified | UL Listed

      Warranty:

      1 Year
